Fletcher-Munson Curve Explained: Impact On Audio Engineering

March 9, 2024
BY DAN SPENCER
Fletcher-Munson Curves
Last Updated on March 9, 2024

Have you ever wondered why some sounds feel louder than others, even when they're at the same volume? Enter the fascinating world of the Fletcher-Munson Curve, a key concept that shines a light on our unique hearing experience. Developed in the 1930s by Harvey Fletcher and Wilden A. Munson, this discovery explains why our perception of loudness changes with different frequencies. In this post, we'll dive into what the Fletcher-Munson Curve is, why it matters, and how it impacts everything from the way we enjoy music to the design of audio equipment. Get ready to explore how our ears work and why this curve plays a pivotal role in audio engineering.

What Are The Fletcher-Munson Curves?

Chart of the Fletcher-Munson curves.
Credit: WikiMedia Commons

Introduction To The Fletcher-Munson Curves

The Fletcher-Munson Curves are pivotal in understanding how we perceive sound. Named after Harvey Fletcher and Wilden A. Munson, these curves reveal that our ears do not perceive all frequencies with equal sensitivity. This discovery, made in 1933, opened up a new dimension in audio science, illustrating how different sounds at the same volume can appear to have varying loudness to the human ear.

The Discovery And Its Importance

Harvey Fletcher and Wilden Munson's research showed the subjective nature of our hearing through what are known as equal-loudness contours. These graphs demonstrate our ears' biased sensitivity towards sounds in the mid-frequency range, where most human speech occurs, and a relative insensitivity to very low and very high frequencies.

Equal-Loudness Contours Explained

Equal-loudness contours, plotted on a graph with frequency on the x-axis and loudness level (in phons) on the y-axis, illustrate this phenomenon. Frequencies between 2 kHz and 5 kHz are perceived as louder compared to lower bass or higher treble notes at the same sound pressure level (SPL). This unequal sensitivity across the sound spectrum is crucial for audio engineers and designers of audio equipment, as it influences everything from music production to the creation of headphones and speakers.

How We Perceive Sound

The intricacy of human hearing extends beyond a simple linear relationship between the frequency (Hz) and loudness (dB) of a sound. Our perception of loudness changes with frequency, necessitating more energy (or dB SPL) at lower and higher frequencies for a sound to be perceived as equally loud when compared to mid-frequency sounds. This nonlinear perception is quantified in phons, providing a measure of perceived loudness levels. Sones like phons measures perceived loudness but on a linear scale.

Frequency (Hz)Loudness Level (Phons)Perceived Loudness (Sones)
20401
100402
1000404
5000408
100004015
The table above provides insights into the non-linear relationship between frequency and perceived loudness at a constant phon level, underlining how our hearing sensitivity varies across different pitches.

Fletcher-Munson Curves In Audio Engineering

Audio engineer mixing in the studio.

Tailoring Music Production And Mixing

Understanding the Fletcher-Munson Curves is crucial for audio engineers aiming to create balanced mixes. By acknowledging that listeners perceive frequencies at different degrees of loudness, they can sculpt the sound to ensure clarity and fullness across the entire audio spectrum. For instance, knowing that the human ear is less sensitive to low and high frequencies, engineers might boost bass and treble levels to compensate, ensuring these elements are not lost in the mix.

The More You Know: 80 dB SPL is the ideal mixing level based upon the Fletcher-Munson curves.

Designing Audio Equipment With Human Hearing In Mind

The knowledge of equal-loudness contours directly influences the design of audio playback equipment, including headphones, speakers, and amplifiers. Manufacturers strive to engineer products that cater to the natural sensitivity curves of the human ear, aiming for a frequency response that delivers a more natural and pleasing sound. This involves tuning devices to emphasize or de-emphasize certain frequencies, in line with the Fletcher-Munson Curves, to compensate for our ears' non-linear response to sound pressure levels across different frequencies.

Enhancing Sound Quality In Varied Listening Environments

The application of the Fletcher-Munson Curves extends beyond music production and equipment design to the optimization of sound in various environments, such as concert halls, cinemas, and living rooms. Acoustical engineers use insights from these curves to tailor the audio output for specific spaces, ensuring that sound levels are comfortable and speech is intelligible. This could mean adjusting the sound system to emphasize certain frequencies more than others or designing the acoustics of a room to naturally boost or absorb specific sound waves, creating an optimal listening environment for the audience.

Tips For Audio Engineers

Closeup of an audio engineer moving faders on a mixing console.

So far we've learn that we don't hear all sounds at the same loudness, even if they're technically played at the same volume. This is super helpful to know because it means you can tweak your mix to make sure everyone hears your music just right, no matter what speakers they're using. You'll learn to dodge those common mixing traps, like mixes that have way too much bass or ear-splitting highs, which might sound okay on your studio monitors but nowhere else.

Then, there's mastering, where Loudness Units full scale (LUFS) come into the spotlight. This measurement unit matches up with the Fletcher-Munson curve to give you a solid benchmark for how loud your track should be. Why does this matter? Well, it helps make sure your song hits just the right volume on Spotify, YouTube, or wherever else it might land. Keeping your tracks consistent with LUFS is key to making sure people stick around and listen, instead of skipping to the next song because the volume was all over the place.

Here are some tips to implement when mixing and mastering music:

  • Measure your SPL playback while mixing a song. Increase or decrease your speaker volume until it is around 80 dB. If you don't have professional tools to do this, there are plenty of adequate phone apps out there that can measure SPL.
  • Use a tool like Izotope Tonal Balance Control 2 to make sure you are balancing the frequency spectrum properly.
  • Utilize LUFS to calibrate your audio's loudness, ensuring consistent playback across different streaming services. We shoot for a integrated LUFS level of between -8 and -11 dB.

Frequently Asked Questions (FAQs)

What are phons?

Phons are a unit of measure that represent the perceived loudness of a sound by a listener. The phon scale is based on the human ear's sensitivity to different frequencies. It adjusts for the fact that we perceive some frequencies as being louder than others, even if they have the same physical sound pressure level. One phon is equivalent to one decibel of sound pressure level at a frequency of 1 kHz, which is used as the reference point.

What is LUFS, and how does it relate to the Fletcher-Munson Curves?

LUFS stands for Loudness Units relative to Full Scale, a standardized measure of audio loudness that takes into account human perception, similar to what the Fletcher-Munson Curves describe. It's used to ensure consistent perceived loudness across different music platforms.

What is an equal-loudness contour?

Equal loudness contours are lines on a graph that represents sounds of different frequencies perceived as equally loud by the average listener. These contours form the basis of the Fletcher-Munson Curves.

Are the Fletcher-Munson Curves applicable to all types of audio, including speech?

Yes, these curves are relevant to all audible sounds, including music, sound effects, and speech. Understanding them can help in various audio applications, from designing public address systems to producing podcasts, ensuring clear and balanced audio output across different frequencies.

Have the Fletcher-Munson Curves been updated or replaced?

Yes, the original curves have been updated and refined over the years. The most recent standard is known as ISO 226:2003, which provides an updated set of equal-loudness contours based on more recent research.

Final Thoughts

The Fletcher-Munson Curve isn't just a piece of audio trivia; it's a fundamental principle that guides the creation of sound that's true to life and enjoyable across all listening environments. Whether you're mixing, mastering, or simply tuning into your favorite song, the insights from Fletcher and Munson remind us that the art of sound is deeply rooted in the science of hearing. By applying these principles, we not only elevate our craft but also enhance the listening experience for everyone, making music and sound more accessible and enjoyable. So, here's to the science behind the sound, and to creating audio masterpieces that resonate with listeners everywhere!
